DY-1580SL MACHINE CONFIGURATION
|
NO. |
ITEM |
BRAND |
|
1 |
Control system |
FANUC, Mitsubishi, SIEMENS, HEIDENHAIN SYNTEC, HNC all selectable. |
|
2 |
Linear guide brand |
HIWIN / PMI class P4 |
|
3 |
Ballscrews |
HIWIN / PMI class C3 |
|
4 |
X/Y/Z ballscrews standard |
6310 / 6310 / 5010 |
|
5 |
X/Y/Z Linear guide size |
55 / 45 / 55 |
|
6 |
Spindle |
AIBIG / DEJO |
|
7 |
Tool magazine |
POJU / DEJIE / SANJET |
|
8 |
Bearing |
FAG / NSK from Germany |
|
9 |
Cooling pump |
DUYANG |
|
10 |
Lubrication system |
(China) HERG / BAOTN |
Question and Answer
- What is the warranty period for the control system of Kunshan Duyang?
Kunshan Duyang mainly adopts the control systems of Mitsubishi Mistubish M80 and fanuc 0i-mf from Japan. Duyang provides customers with a one-year free warranty service. For users in some special regions who need to extend the warranty to two years, please contact us for specific consultation.
- Regarding the power distribution plan for the control system?
We mainly choose the distribution products of Binjie and Zhehong brands. When the equipment is equipped with a tool setter, probe or fourth axis, Kunshan Duyang usually recommends the Binjie brand because it is more convenient to integrate and easier to operate.
| DY-1580SL TECHNICAL PARAMETER | |||||
| ITEMS | UNIT | PARAMETER | |||
| WORKTABLE | |||||
| Table size | mm | 1700×800 | |||
| T slot(number-width-pitch) | mm | 5-22×135 | |||
| Max.worktable load | kg | 1500 | |||
| AXIS TRAVEL | |||||
| X/Y/Z axis trave | mm | 1500/800/700 | |||
| Distance from spindle nose to worktable surface | mm | 170-870 | |||
| Distance from spindle axis to Column surface | mm | 850 | |||
| SPINDLE | |||||
| Taper and specificationof main shaft | BT50-Φ155 | ||||
| Max.spindle speed | rpm | 8000 | |||
| Spindle connection style | Belt | ||||
| Spindle power | KW | 15 | |||
| TOOL MAGAZINE | |||||
| ATC system | |||||
| Tool magazine capacity | pcs | 24 | |||
| Tool shank type | BT50 | ||||
| Max tool weight | kg | 15 | |||
| Max tool length | mm | 300 | |||
| Time of tool change (T-T) | s | 2.2 | |||
| Max tool diameter (w/o adjacent tools) | mm | Φ110 | |||
| FEEDRATE | |||||
| Max. displacement speed(X/Y/Z) | m/Min | 24/24/18 | |||
| DY-1580SL TECHNICAL PARAMETER | |||||
| ITEMS | UNIT | PARAMETER | |||
| ACCURACY | |||||
| X/Y/Z axis positioning accuracy | mm | 0.005 | |||
| X/Y/Z axis repeatability accuracy | mm | 0.005 | |||
| MACHINE SIZE | |||||
| Machine size(L×W×H) | mm | 4420×3230×2400 | |||
| PACKAGE SIZE | |||||
| Package size | mm | 4600×3400×2500 | |||
| MACHINE WEIGHT | |||||
| Net weight / Gross weight | kg | 10000 / 11000 | |||
